RM-4E Reader Interface

RM-4E READER

INTERFACE

You can interface read heads that supply Wiegand signaling or magnetic

(ABA) signaling to the apC/8X, iSTAR, and iSTAR Pro using RM-4E

boards.

Figure 3 indicates how an RM-4E board interfaces with Wiegand and

Magnetic signaling read heads.

FIGURE 3. RM-4E Interface

NOTE UL has not evaluated magnetic (ABA) signaling read heads.
