83
18. MISSING LINE MEASUREMENT
Missing line measurement is used to measure the slope distance, horizontal
distance, and horizontal angle to a target from the target which is the reference
(starting point) without moving the instrument.
• It is possible to change the last measured point to the next starting position.
• Measurement result can be displayed as the gradient between two points.
XPROCEDURE
1. Sight the target of the starting
position, and press [DIST] in the
first page of Meas mode to begin
measurement.
The measured values are
displayed.
Press [STOP] to stop
measurement.
18.1 Measuring the Distance between 2 or more
Points
