8.2 TIG LIFT Settings
After installing as described in Par. 7.3, select the TIG
LIFT mode by pressing the MODE button.
Adjust the welding current with the knob (20), the value
will be shown on the display (16).
8.3 MIG/MAG Settings
After installing as described in Par. 7.4, select the
AlMg1.0 or JOB-LIST mode by pressing the MODE
button and the 2T, 4T or SPEC 4T cycle by pressing the
CYCLE button, see Par. 8.4.
MANUAL Regulation
In ALMg1.0 and JOB-LIST MODE, it is possible to obtain
a NON-synergic regulation by setting submenu P19 to
ON. See Par. 8.5.
- Adjust the WELDING CURRENT with the knob (20).
- Adjust the ARC VOLTAGE with the knob (21).
Press the knob (20) for at least 5 s to obtain a WIRE
SPEED adjustment, in this case adjust the desired m/min
on the right display.
Press again for at least 5 s to return to the CURRENT
setting.
