Instruction Manual - Technical Section
PLUS 210 C
(*) = Suggested spare parts / Ricambi consigliati
Pos.
Qty
DESCRIPTION
PLUS 210 C
PART No.
1
1
Circuit breaker
K410IN
2
2
Rectifier bridge
735004-00006
3
4
Thermistor
720022-00013
4
2
Fan
K409VE
5
1
Varistor
720021-00020
6
1
Polypropylene capacitor
722001-00023
7
2
Polypropylene capacitor
722001-00011
8
3
Aluminum electrolytic capacitor
722004-00105
9
8
IGBT tube
735003-00013
10
1
Temperature relay
745008-00032
11
1
Main transformer
763002-00026
12
8
Diode
730001-00007
13
2
Output reactor
763005-00023
14
1
Main control drive PCB (*)
V16676SC
15
1
Display PCB (*)
V16678SC
16
1
Power transformer
M374TP
17
1
Wire feeder group with motor (not visible)
321017-0002
1x
1x
Installed serial rolls:
V-type roll STEEL 0,8 - 1,0
V-type roll STEEL 1,0 - 1,2
No code
No code
1x
1x
Optional rolls:
V-type roll for FLUX-CORED (knurl) 0,8 - 1,0
U-type roll ALUMINUM 1,0 - 1,2
327005-00079
327005-00082
18
1
Solenoid valve DC24V (*)
K411EV
19
2
Quick socket
740002-00091
20
1
Euro torch connector
766003-02545
21
1
Power supply filter PCB
V16677SC
