65
L20, L30
Model
L20
L30
PF (100% R Load)
>0.99
Frequency tolerance
40-70Hz
Voltage window (At
100%/50% load)
176-280Vac or 305-485Vac, Full load
80-280Vac or 138-485Vac, <40% Load
Back feed contact point
Dry contact: 125Vac/0.5A
Power Walk IN(S) for parallel
system
1-200
Dual feed
Standard with busbar configuration as single feed
Nominal Input rate current(A)
380V：32A
400V：31A
415V：30A
380V：48A
400V：46A
415V：44A
Max Input current(A)
380V：40A
400V：38A
415V：37A
380V：60A
400V：57A
415V：55A
Battery
Battery types
VRLA
Build-in battery
60pcs 9Ah
60pcs 9Ah
±120Vdc
±180Vdc
Battery block flexibility
Optional Voltage:±
96/108/120/132/144/156Vd
c (16/18/20/22/24/26pcs
optional) 192Vdc～
312Vdc (16~26pcs, 20
pcs to
define, 20~ 26pcs no power
derating; 18pcs output
power factor 0.9;16pcs
output power factor 0.8;)
Optional Voltage:
±180/±192/±204/±216/±2
28/±240/±252/±264/±276/
±288/±300Vdc(30/32/34/3
6/38/40/42/44/46/48/50pcs
optional)
360Vdc~600Vdc (30~50
pcs, 30 pcs define, 36~ 50
pcs no power derating;
32~34 pcs output power
factor 0.9;30 pcs output
power factor 0.8;)
Charge capacity
13A Max.
Battery temperature
compensation (standard /
optional)
40℃/104°F＞T＞25℃
/
82.4 °F , -7~0mV/
℃
，
default： no compensation
