L20, L30

Model

L20

L30

Cooling

Cooling type

(heat pipe,

liquid, air)

Air

Air flow

input /

output

Air inlet: front

Air outlet: rear

Internal

Breaker

Internal

Mains

40A 3P

63A 3P

Internal

bypass

40A 3P

63A 3P

Internal

maintenance

bypass

40A 3P

63A 3P

Internal

output

40A 3P

63A 3P

User interface

Display

Color touch screen, 7 inches

SNMP card

(optional)

Megatec SNMP

Relay card

(optional)

Relay card

Communicati

on port

USB, S232, RS485, Parallel, Battery temperature

sensor(optional)

Dry contact

port

Maintenance breaker dry contact port, Output

EPO

Yes, remote EPO

Language

8 main language (English, French, Simplified Chinese,

Spanish, German, Russian, Italian, Brazilian-Portuguese)

Environmental
