SolarEdge SE Series User Manual

 SE33.3K SE40K Unit
Applicable to inverters with
part numbers
SEXXK-XXX8IXXXX 
DC Fuses (model dependent) 25 ,Optional A
Compliance UTE-C15-712-1 
Standard Compliance   
Safety IEC-62109, AS3100 
Grid Connection Standards
(1)
VDE-AR-N-4105,AS-4777,EN50438,
CEI-021, VDE 0126-1-1,CEI-016,
EN50549-1,EN50549-2,VDE-AR-N-
4110,TOR Erzeuger Typ A,G99, G99
(NI),VFR 2019

Emissions
IEC61000-6-2, IEC61000-6-3 Class A,
IEC61000-3-11, IEC61000-3-12

WEEE,RoHS Yes 
Iinstallation Specifications   
AC output of Inverter:
Gland Cable Diameter
Line wire cross section
PE cross section

19 - 28 mm
4 - 16 mm
2
4 - 16 mm
2
AC output of DC Safety Unit:
Cable diameter of AC gland
Cable diameter of PE gland
Cross section of line wire
Cross section of PE wire

19 - 28 mm (model dependent)
5 - 10 mm
4 - 16 mm
2
4 - 16 mm
2
DC Input
(2)
 4 MC4 pairs
DC Input with Safety Unit
(2)

Configuration 1: 4 MC4 pairs
Configuration 2:  4 Strings: Gland cable diameter 5 - 10
mm
Wire cross section 2.5 - 16mm
2
Dimensions (HxWxD) 558 x 328 x 273 mm
(1)
For all standards refer to Certifications category in Downloads page:
http://www.solaredge.com/groups/support/downloads
(2)
Only MC4 connectors manufactured by Stäubli are approved for use
Three Phase Inverter with SetApp Configuration PN: SEXXK-XXXXIXXXX
77 Three Phase Inverter for the 277/480V Grid - SE33.3K, SE40K

SolarEdge SE Series Specifications

General

Efficiency	Up to 99%
Protection Rating	IP65
Communication	Ethernet, Wi-Fi (optional), RS485
Dimensions	Varies by model
Weight	Varies by model
Rated AC Power	Varies by model
Max. DC Power	Varies by model
Model	SE Series (e.g., SE3000H, SE5000H)
AC Output Power	Varies by model
MPPT Range	Varies by model
Operating Temperature	-25°C to 60°C
Warranty	12 years standard, extendable to 20 or 25 years
