Page #17 background imageLoading...
Page #17 background image
Two types of power optimizers are available:
Panel Module Add-on power optimizer – connected to one or more modules
Smart modules - the power optimizer is embedded into a module
Inverter
The inverter efficiently converts DC power from the modules into AC power that can be
fed into the main ACservice of the site and from there to the grid. The inverter also
receives the monitoring data from each power optimizer and transmits it to a central
server (the monitoring platform; requires Internet connection).
Some inverters are available with an optional DC Safety Unit. The DC Safety Unit has a
manually operated switch for disconnecting the DC power of a SolarEdge system.
The DC Safety Unit is located below the inverter and is connected to the inverter with
AC and DC wires.
Monitoring Platform
The monitoring platform enables monitoring the technical and financial performance of
one or more SolarEdge sites. It provides past and present information on the system
performance both at the system and module levels.
Installation Procedure
The following is the procedure for installing and setting up a new SolarEdge site. Many
of these also apply to modification of an existing site.
1. Connecting Power Optimizers in Strings, page 23
2. Recording power optimizer serial numbers (optional), page 41
3. Mounting the inverter, Page 25
4.
Connecting the AC and the Strings to the Inverter, page 30, or Connecting the AC
and the String to the DCSafety Unit, page 84
5.
Commissioning and activating the installation, page 35
6. Connecting the inverter to the monitoring platform, page 42
7.
Configuring the inverter, page 44
Installation Equipment List
Standard tools can be used during the installation of the SolarEdge system. The
following is a recommendation of the equipment needed for installation:
Allen screwdriver for 5mm screw type for the inverter enclosure screws
Three Phase System MAN-01-00507-4.2
16  Inverter
