The following shows a hierarchical tree of the menu options, which are described in
Configuration Menu Options
on page 51. Actual menus may vary from shown
depending on the firmware version of the inverter and on the country.
Main menu:
C o u n t r y < I t a l y >
L a n g u a g e < E n g >
C o m m u n i c a t i o n
P o w e r C o n t r o l
D i s p l a y
M a i n t e n a n c e
I n f o r m a t i o n
Country:
G e r m a n y +
S p a i n
F r a n c e
.
.
.
Language:
E n g l i s h
G e r m a n
S p a n i s h
F r e n c h
I t a l i a n
Communication
(1)
:
S e r v e r < L A N >
L A N C o n f
R S 4 8 5 – 1 C o n f < S >
Z i g B e e C o n f < S >
W i - F i C o n f < N / A >
C e l l u l a r C o n f
G P I O C o n f < M T R >
Power Control
(2)
:
(1)
If ZigBee is connected, the Wi-Fi Conf menu is not displayed. If ZigBee is not connected, ZigBee Conf and
Wi-Fi Conf are both displayed with <N/A>.
(2)
Phase Balance is applicable to single phase inverters only.
Chapter 6: User Interface 47
Three Phase System MAN-01-00507-4.2
