Display:
T e m p e r a t u r e < C >
L C D O n T i m e < 3 0 >
T L M O n T i m e < 1 5 >
Maintenance:
D a t e a n d T i m e
R e s e t C o u n t e r s
F a c t o r y R e s e t
F W U p g r a d e
D i a g n o s t i c s
G r i d P r o t e c t i o n
B o a r d R e p l a c e m e n t
Information:
V e r s i o n s
E r r o r L o g
W a r n i n g l o g
H a r d w a r e I D s
Configuring the Inverter Using the LCD Light Button
Use the LCD light button for communication setup and for displaying the Error log and
Warning Log without having to open the Inverter cover. There are fewer menus
available when using this configuration option; however, the functionality of these
menus is the same as when using the internal LCD user buttons.
1. Turn the inverter ON/OFF switch to OFF.
2.
Press and hold down the LCD light button until the following message is displayed:
K e e p h o l d i n g b u t t o n
f o r p a i r i n g , r e l e a s e
t o e n t e r m e n u . . .
R e m a i n i n g : 3 s e c
Releasing the button displays the following menu:
O p t i m i z e r p a i r i n g
L a n g u a g e < e n g >
C o m m u n i c a t i o n
M a i n t e n a n c e
I n f o r m a t i o n
E x i t
3. Short-press (one second) to scroll down to the next menu option, and long-press
(three seconds) to select the item. You can use the Exit option in these menus to
move up one menu level or to exit the Setup mode from the main menu.
Chapter 6: User Interface 49
Three Phase System MAN-01-00507-4.2
