E n e r g y M a n a g e r
R R C R C o n f .
R e a c t i v e P w r C o n f .
A c t i v e P w r C o n f .
P h a s e B a l a n c e < D i s >
W a k e u p C o n f .
P ( f )
A d v a n c e d
L o a d D e f a u l t s
Power control options are detailed in the
Power Control Application Note
, available on
the SolarEdge website at http://www.solaredge.com/files/pdfs/application_note_
power_control_configuration.pdf.
The Grid Control option may be disabled. Enabling it opens additional
options in the menu.
The Energy Manager option is used for setting power export limitation,
as described in the
Export Limitation Application Note
, available on the
SolarEdge website at
http://www.solaredge.com/files/pdfs/products/feed-in_limitation_
application_note.pdf.
For P(Q) diagram refer to
https://www.solaredge.com/sites/default/files/application_note_p_q_
diagram_of_se_inverters_en_and_na.pdf
NOTE
SolarEdge inverters with “Grid Support” functionality (as marked on the
inverter certification label), are compliant with UL1741 Supplement A. The
functionality is built into the inverter and no additional external device is
required.
Display
Select Display to set the following:
T e m p e r a t u r e < C >
L C D O n T i m e < 3 0 >
T L M O n T i m e < 1 5 >
Temperature: Select Celsius or Fahrenheit units.
LCD On Time <30>: The number of seconds that the LCD backlight is ON after
pressing the LCD light button. Set a value within the range of 10-120 seconds.
Three Phase System MAN-01-00507-4.2
54 Configuration Menu Options
