Energy Meter Status
Displays the total energy produced during the last day, month, year and since inverter
installation.
D a y [ W h ] : 0 . 0
M o n t h [ K W h ] : 0 . 0
Y e a r [ K W h ] : 0 . 0
T o t a l [ K W h ] : 0 . 0
Day: since midnight
Month: since 1st of the current month until today (inclusive)
Year: since January 1st until today (inclusive)
If a meter is connected to the inverter, the following status screen, showing the power
and energy readings, is displayed in addition to the above screen.
If the meter is set to Export +Import, there are two status screens, with the first line
displaying: "Export Meter" or "Import Meter". The following is an example of an export
meter status:
E x p o r t M e t e r
S t a t u s : < O K / E r r o r # >
P o w e r [ W ] : x x x x x . x
E n e r g y [ W h ] : x x x x x . x
Status: Displays OK if the meter is communicating with the communication board.
<Error message>: If there is a meter error, it is displayed in this line.
Power (W): Depending on the meter type connected to the inverter, this line
displays the exported or imported power in Watts.
Energy (Wh): The total energy read by the meter, in Watt/hour. The value displayed
in this line depends on the meter type connected to the inverter and its location:
If a bidirectional meter is connected at the consumption point, this value is the
consumed energy.
If the meter is installed at the production connection point, this value is the
energy produced by the site.
If the meter is installed at the grid connection point, this value is the energy
exported to the grid.
If the inverter is connected to the SolarEdge server, this value will also be displayed in
the monitoring platform.
Chapter 6: User Interface 57
Three Phase System MAN-01-00507-4.2
