NOTE
Additional SolarEdge inverters (without batteries) can be connected with
RS485. The inverters will participate in export limitation and Smart Energy
Management.
PV modules connected to power optimizers are not mandatory for charge/
discharge profile programming.
Installation Equipment List
Standard tools can be used during the installation of the SolarEdge system. The
following is a recommendation of the equipment needed for installation:
Allen screwdriver for 5mm screw type for the inverter cover and inverter side screws
Allen screwdriver for M5/M6/M8 screw types
Safety gloves
Standard flat-head screwdrivers set
Non-contact voltage detector
Cordless drill (with a torque clutch)or screwdriver and bits suitable for the surface
on which the inverter and optimizers will be installed. Use of an impact driver is
not
allowed
Appropriate mounting hardware (for example: stainless bolts, nuts, and washers) for
attaching:
the mounting bracket to the mounting surface
the power optimizer to the racking (not required for smart modules)
Wire cutters
Wire strippers
Voltmeter
For installing the communication options, make sure you have the following:
For Ethernet:
CAT5/6 twisted pair straight Ethernet cable with RJ45 connector
If using a CAT5/6 cable spool: RJ45 connector and RJ45 crimper
For RS485:
Four- or six-wire shielded twisted pair cable.
Watchmaker precision screwdriver set
Chapter 1: Overview 11
StorEdge Three Phase Inverter MAN-01-00648-1.3
