Ground-Fault Isolation Detection 700kΩ Sensitivity
Maximum Inverter Efficiency 98 %
European Weighted Efficiency 97.3 97.4 97.6 %
Nighttime Power Consumption < 2.5 W
INPUT BATTERY
Maximum DC Power 5000 W
Input Voltage Range 40- 62 Vdc
Maximum Continuous Input
Current
130 Adc
Battery Communication CAN, RS485 (optional)
ADDITIONAL FEATURES
Supported Communication
Interfaces
2 x RS485, Ethernet, Zigbee communications
for Smart Energy (requires antenna)
(1)
, Wi-Fi
(requires antenna)
(2)
, Built-in GSM (optional)
STANDARD COMPLIANCE
Safety IEC-62103 (EN50178), IEC-62109
Grid Connection Standards
(2)
VDE 0126-1-1, VDE-AR-N-4105, AS-4777, G83 /
G59
Emissions
IEC61000-6-2, IEC61000-6-3, IEC61000-3-11,
IEC61000-3-12
RoHS Yes
INSTALLATION SPECIFICATIONS
AC Output – Cable Gland Diameter 15 - 21 mm
Battery DC – Cable Gland Diameter 2 x 8-11 mm
PV DC Input 2 x MC4 pair
Dimensions (HxWxD) 853 x 316 x 193 mm
Weight 37 kg
Operating Temperature Range -40 - +60 ˚C
Cooling Internal and external fans
Noise < 50 dBA
(1)
Antenna kit for ZigBee/Wi-Fi communication should be purchased separately
(2)
For all standards refer to Certifications category in Downloads page:
http://www.solaredge.com/groups/support/downloads
StorEdge Three Phase Inverter MAN-01-00648-1.3
67 StorEdge Three Phase Inverter - Technical Specifications
