SolarMax 5000P - Mains and PV Generator Connections

82
5.3 Connecting the inverter to the mains
DANGER!
Fatal electric shock hazard!
 Make sure the AC line is not live during connection work.
Connection conditions
 Comply with the connecting conditions set by the grid operator in charge.
 Connectable cable diameter: min. 9.5 mm / max. 12.5 mm
 Permissible conductor cross-sections:
– exible conductors (with or without ferrule) or rigid conductors: max. 16 mm
2
– exible conductors with ferrules (with plastic sleeves): max. 10 mm
2
 The AC feed cable must be fused.
 Minimum conductor cross sections and suggested mains fuses:
SM2000P SM3000P SM4000P SM4600P SM5000P
Minimum conductor cross-section 1.5 mm
2
1.5 mm
2
2.5 mm
2
4 mm
2
4 mm
2
Mains fuses (characteristic C) 10A 16A 20A 25A 25A
 Make sure the ambient temperatures for the mains fuses specied by the producer
are not exceeded.
WARNING!
Risk of death by fire!
 Provide separate fuses for each inverter.
 Do not attach any loads between inverter and fuse.
 If you use an external leakage current circuit breaker (RCD switch), you must comply
with the following connection conditions:
– Use an A type RCD (residual current device) switch with a rated fault current of at
least 100 mA.
– In PV power plants with high leakage capacities, an RCD switch with a rated fault
current of at least 300 mA. must be used.
