3.2 External operating elements and dimensions
Front view
1
750mm
550mm
1
Graphics display with status LED and three buttons
Side view left
21 3
200mm
1
Fan cover (air intake)
2
DC disconnector Q1
3
Connection option for external protective conductor
Side view right
1
1
Fan cover (air outlet)
