32
7 Mechanical Installation
WARNING!
• Only the qulalified personel can perform the mechanical installation following the
local standards and requirements.
• Check the existing power cables or other piping in the wall to prevent electric shock
or other damage.
CAUTION!
• Always be aware of the weight of the inverter. Personal injuries may result if the
inverter is lifted improperly or dropped while being transported or mounted.
• Use insulated tools when installing the device. Personal protective equipment must
be worn during installation and maintenance.
NOTICE!
• Install the inverter at a maximum back tilt of 5 degrees and avoid forward tilted, side
tilted, or upside down.
≤5°
90°
Figure 7-1 Correct installtion
Figure 7-2 Incorrect installation
