8 Electrical Connection
DANGER!
• Before electrical connection, make sure the DC switch and AC breaker are
disconnected. Otherwise, electrical shock may be caused by high voltage, resulting in
serious personal injury or death.
WARNING!
• Only the qulalified personel can perform the electrical connection following the local
standards and requirements.
• Follow this manual or other related document to wire connection. The device
damage caused by incorrect cabling is not in the scope of warranty.
WARNING!
• Use insulated tools and wear individual protective tools when connecting cables.
8.1 Terminals of Inverter
BA B B D
G I J
C E F
Figure 8-1 Terminals of Inverter
