Solcon HRVS-DN User Manual

Parameter Settings
26
2626
26
Press Mode
To Advance to:
START PARAMETERS
Press Select
SOFT START CURVE
1 (STANDARD)
Then press  keys to set Soft Start Curve:
0 = Basic
1 = Standard Curve
2!! = Pump Control Curve # 1
3!! = Pump Control Curve # 2
4!! = Pump Control Curve # 3
5!! = Torque Control
When setting dip switch # 2 to on for Tacho Mode
Press   and curve message changes to:
START TACHO. GAIN
0 (MIN. GAIN)
Then press  keys to set Tacho gain:
0 = Minimum gain tacho control.
1!! = Second level Tacho gain.
2!! = Third level Tacho gain.
3!! = Fourth level Tacho gain.
4!! = Fifth level Tacho gain.
5!! = Sixth level Tacho gain.
Note: Tacho feedback is operational in its basic
form. Additional curves except for the basic
linear curve are optional. Consult factory for
correct tacho selection and mechanical
installation.
Press Select ,
Press  keys to set Pulse Level.
Range: 70-700% of motor FLA. If Pulse Time is
longer than 1 sec then max value of pulse level is
limited to 440x( STARTER FLC / MOTOR FLA ) [%]
PULSE LEVEL
70% OF FLA
Press Select ,
Press  keys to set Pulse Time.
Range: 0-10 sec.
PULSE TIME
0 SEC.
Note: Pulse Start has no effect with Start Curve = 0
Press Select ,
Press  keys to set Initial Voltage.
Range: 10-50% of Un for voltage ramp.
INITIAL VOLTAGE
30%
If you use curve 0 or 1 it is possible to increase the
current within the range 100-400% of In.
The display changes to:
INITIAL CURRENT
100% OF FLA
Press Select
,
Press  keys to set Current Limit
Range: 100-400% of motor FLA.
CURRENT LIMIT
400% OF FLA
Press Select
Press  keys to set Acceleration Time
Range: 1-30 sec.
ACC. TIME
10 SEC.
Press Select
Press  keys to maximum Start Time.
Range: 1-30 sec.
MAX. START TIME
30 SEC.
Press Select
Press  keys to set the number of starts permitted
(during START period below)
Range: 1-10, Off.
NUMBER OF STARTS
1
Press Select
Press  keys to set number of starts time period.
Range: 1-60 min.
STARTS PERIOD
20 MIN.
Press Select
Press  keys to set start inhibit period
Range: 1-60 min.
START INHIBIT
15 MIN.
Press Select
Press  keys to set time delay for the end of
acceleration contact.
Range: 0-120 sec.
RUN CONTACT DEL.
5 SEC.
Press Select
To store selected parameters, press Store key.
STORE ENABLE
START PARAMETERS
When parameters have been correctly stored the LCD
reads:
DATA SAVED OK.
This includes START PARAMETERS settings.
