Parameter Settings
28
2828
28
Press Mode
Set Dip Switch # 1 to ON to advance to:
FAULT PARAMETERS
Press Select
Then press
keys to set Auto.Reset for
Under-Voltage and Phase loss faults. Range:
Yes/No.
UV & PL AUTO RST
NO
Press Select
Then press
keys to set Under Current Auto
Reset.
Range: 10-120min / Off
UNDER CUR. RESET
OFF
Press Select
Then press
keys to set By Pass open trip.
Range: Enable\ Disable.
BY PASS OPEN TRIP
ENABLE
Press Select
Then press
keys to set trip after By Pass.
Range: Enable\ Disable.
Can be used to disable most of fault protections
starting 30 seconds after by-pass is closed.
Use only if another protection relay is used.
TRIP AFTER BY PASS
ENABLE
Press Select
Then press
keys to set By Pass auto reset.
Range: Yes \ No.
BY PASS AUTO RESET
NO
Press Select
Then press
keys to enable or disable “SET CURVE 0
FLT”.
Range: Enable\ Disable.
Set to disable, only if “SET CURVE TO 0” fault occurs
during starting and if curve 0 starting process is not good
enough for the application.
When set to disable verify that motor starts normally in the
selected curve.
SET CURVE 0 FLT
ENABLE
Press Select
Then press
keys to set Powe On and no start
protection. Range: Enable\ Disable.
PWR ON & NO STRT
ENABLE
Press Select
Then press
keys to set Insulation alarm level.
Range: Off, 0.2 – 20Mohm
INSULATION ALARM
OFF
Press Select
Then press
keys to set Insulation alarm trip.
Range: Off, 0.2 – 20Mohm
INSULATION TRIP
OFF
Press Select
To store selected parameters press
Store
key
STORE ENABLE
FAULT PARAMETERS
When parameters have been correctly stored, the LCD
displays:
DATA SAVED OK
This concludes
FAULT PARAMETERS
setting.
To Next Page
