SOLIS S6-EH3P5K2-H - PE Cable Installation

User Manual
4. Installation
11
An external ground connection is provided at the right side of inverter.
Prepare OT terminals: M4. Use proper tooling to crimp the lug to the terminal.
Connect the OT terminal with ground cable to the right side of inverter. The torque is 2N.m.
4.3 PE Cable Installation
Figure 4.5 Co nn e ct t he e xt e rn al g rou nd in g c on du cto r
Grounding screw
Grounding screw
