1. Introduction
2
User Manual
1.1 Product Description
The Solis S6 Series is designed for residential hybrid systems, which can work with batteries
to optimize self-consumption. The unit can operate in both off- and on-grid modes.
This manual covers the Solis S6 Series inverter model listed below:
S6-EH3P5K2-H, S6-EH3P6K2-H, S6-EH3P8K2-H, S6-EH3P10K2-H,
S6-EH3P5K-H-EU, S6-EH3P6K-H-EU, S6-EH3P8K-H-EU, S6-EH3P10K-H-EU
The following models are exclusively for the Polish market:
S6-EH3P3K-H-EU, S6-EH3P4K-H-EU
The following model is designed for the Belgian market:
S6-EH3P10K-H-EU-BE
Figure 1.1
Front side view
Figure 1.2
Bottom side view
DC Switch
AC Grid Port
AC Backup Port
Data Logging
Stick (Optional)
AntennaPV Input
Battery Input
AC- GRIDAC- BACKU P
ANT ENNA
COM
PV1 PV2 PV3 PV4 BAT
DC Switch
Communication
