Setting Up and Using the I-V Measurement Unit and SolSensor
2-37
Mounting SolSensor on a tripod
Tripod mounting allows more flexibility in locating SolSensor for best wireless range. Tripod mounting
is also useful when it is not feasible to access the array. In this case you can set the PV Analyzer
software to derive the module cell temperature from the measured I-V curve. To deploy SolSensor on a
tripod, you will need the following equipment (contact support@solmetric.com for specific equipment
recommendations):
1. Sturdy tripod
2. Tripod level indicator
This is typically a disc with a bubble level that mounts between the tripod and the rest of
the fittings described here. Some tripods have a built-in level indicator. Note: level
indicators vary widely in their sensitivity and accuracy.
3. Tripod leveling head
This device enables you to quickly and conveniently create a level mounting surface,
without needing to adjust the legs of the tripod.
4. Panning unit
This device rotates about the vertical axis, allowing you to adjust the azimuth of
SolSensor independent of the tilt.
5. Tilt unit
This device rotates about a horizontal axis, allowing you to set the tilt independent of the
azimuth. Typically, you will mount the tilt unit on the panning unit, which is in turn
mounted on the leveling indicator and the leveling unit and the tripod itself.
6. Adapter plate
Firmly attach this plate to the bottom of SolSensor and to the top of the tilt unit.
