UM0027_ SOL APOLLO Series 7.4-22K_EN_V02_0523 47
6 Commissioning and operation
6.1 Mechanical checks
Carry out the main mechanical checks to ensure the EV charger is waterproof
and ready for use.
① Ensure the EV charger has been correctly mounted with the supplied
mounting screws.
② Ensure the AC input cable has been correctly installed.
Warning!
If the AC input cable neutral line is connected opposite to the L line, the
EV charger will become damaged due to the higher voltage.
Figure 42
③ Ensure the communication cable has been correctly wired and secured.
④ Ensure the cable gland has been correctly installed and secured.
Risk of injury due to incorrect installation!
• We strongly recommend carrying out preliminary checks before
commissioning to avoid possible damage to the device caused by
faulty installation.
