3) Shutter for cover is optional
Optional energy meter is needed or must be installed for solar charging
function and Dynamic Load Balancing.
Figure 48
CP
N
L3
L1
L2
PE
PP
CP
N
L3
L1
L2
PE
PP
CP
N
L3
L1
L2
PE
PP
Type2 Plug
Type2 Socket
Type2 Socket with Shutter
The Shutter version socket connector has a shutter on the conductor pins to
prevent accidental contact.
