Cleaning and maintenance
11/2014 1015420-00 Operating instructions – 47/78
7.11 Cleaning or replacing UV lamps and
filter panels in the canopy
– Removing the canopy panel: see page 39.
– Remove the screws and then remove the lamp cover.
The following components listed in the maintenance plan are fitted in the
canopy:
UV low pressure lamps: see page 43.
Facial tanner UV high pressure lamps and filter panels: see page 44.
Facial tanner filter panels
Facial tanner UV low pressure lamps and the associated starters
The facial tanner's UV low pressure lamps must be removed first so that the
UV high presure lamps and the filter panels can be changed.
Type 155023316XXXXXX35:
These devices have 2 UV low pressure lamps in the facial tanner.
– Remove the lamps.
Type 155033316XXXXXX35:
These devices have 3 UV low pressure lamps in the facial tanner.
– Remove the lamps.
