Technical data
11/2014 1015420-00 Operating instructions – 59/78
8 Technical data
8.1 Power rating, electrical specifications
and noise level
Type 155023316XXXXXX35
Nominal power consumption: 12,600 W
Rated frequency: 60 Hz
Rated voltage: 230 V 3 phase 230 V 1 phase
Rated fuses: 40 amp 3-pole 80 amp 2-pole
Noise level at 1 m distance from
the device (without exhaust air):
67.2 dB(A)
Noise level in device: <81 dB(A)
Load on the acrylic panel: max. 300 lb / 135 kg
Weight: approx. 1,157 lb / 525 kg
Type 155023316XXXXXX35 AC PLUS
Nominal power consumption: 13,700 W
Rated frequency: 60 Hz
Rated voltage: 230 V 3 phase 230 V 1 phase
Rated fuses: 50 amp 3-pole 80 amp 2-pole
Noise level at 1 m distance from
the device (without exhaust air):
67.2 dB(A)
Noise level in device: <81 dB(A)
Load on the acrylic panel: max. 300 lb / 135 kg
Weight: approx. 1,173 lb / 532 kg
Type 155033316XXXXXX35 Temptronic
Nominal power consumption: 17,000 W
Rated frequency: 60 Hz
Rated voltage: 230 V 3 phase 230 V 1 phase
Rated fuses: 50 amp 3-pole 80 amp 2-pole
Noise level at 1 m distance from
the device (without exhaust air):
68.9 dB(A)
Noise level in device: <81 dB(A)
Load on the acrylic panel: max. 300 lb / 135 kg
Weight: approx. 1,334 lb / 605 kg
