SOMFY White LED Receiver io User Manual

EN
White LED Receiver io
8
Copyright
©
2018 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved.
3.6. REPLACING A LOST OR BROKEN SOMFY IO CONTROL POINT
To replace a lost or broken io-homecontrol® control point, consult a home motorisation and
automation professional.
3.7. QUESTIONS ABOUT THE WHITE LEDRECEIVER IO?
Observations Possible causes Solutions
The LED light does not react at
all when a button is pressed on
the control point
The batteries in the control
point are weak.
Replace the batteries, using the
same battery model.
The lighting system is faulty. Contact an installer.
4. TECHNICAL DATA
Radio frequency 868-870 MHz io-homecontrol®, two-way
tri-band
Frequency bands and maximum power used 868.000 MHz - 868.600 MHz e.r.p. < 25 mW
868.700 MHz - 869.200 MHz e.r.p. <25 mW
869.700 MHz - 870.000 MHz e.r.p. < 25 mW
Degree of protection IP 55
Electrical insulation
Class III
Operating temperature -20°C to +60°C
Power supply Use an AC/DC power supply providing the SELV
(12V or 24V DC)
Input power 10 A
Output current 3.75A max. per output, 10A max. for the
product as a whole
Nominal power supply voltage 12/24V ±10%
Contact temperature Tc = 80°C
Type of lamps compatible LED controlled at constant voltage
Lamp power or range of lamp powers
compatible
90W max. per output, 240W max. for the
product as a whole
Dimensions of the whiteLEDreceiver io (lxbx h) 190 x 22 x 20 mm
Maximum number of connected control points 3 per output
SOMFY ACTIVITES SA hereby declares that the radio equipment covered by these instructions
is in compliance with the requirements of Radio Directive 2014/53/EU and the other
essential requirements of the applicable European directives.
The full text of the EU Declaration of Conformity is available at www.somfy.com/ce.
