1) Switch off the mains power supply.
2) Connect the whiteLEDreceiver io to one or more white LED lights (A) and to the power supply
unit (B), observing the proper polarity in accordance with the table and illustration below.
A B
W  LED  . B  V
W  LED  . B 
+/V
W  LED  .
W  LED  .
W  V+
Warning
If fewer than 4 LED lights are connected, insulate the unconnected wires of the
whiteLEDreceiver io using individual protection.
3) Secure the white LEDreceiver io (using cable retainers, for example).
4) Connect the 12 V or 24 V power supply unit to the mains.
2.2. COMMISSIONING
This guide only describes commissioning using a 1W io control point.
For commissioning using any other io control point, refer to the corresponding guide.
LED on LED off LED position “my” V   
OFF
B
Ø ≥ 1mm
2
A
