OPERATING MANUAL MPI-530-IT version 1.06
WAADATWR1J
RCD testing adapter TWR-1J
WAPROSONPE5
"SONEL Pomiary Elektryczne" (SONEL
Electrical Measurements) - software for
generating measurement reports
WAPOJ1
battery compartment
WAADAAGT32T
AGT-32T (32A) adapter for single-phase
industrial sockets
WAADAMKZ – k set for MPI-530
WAADAMK – only the keyboard
WAFUTS4 – only the case for the keyboard
Miniature Bluetooth keyboard with case
LSWPLMPI530
calibration certificate
Note
The software is supported by the following systems: Windows XP (Service
Pack 2), Windows Vista and Windows 7.
11.2.1 Clamps C-3
Clamps C-3 are used to measure AC in electrical systems of low and medium power. As optional
accessories for instruments produced by Sonel S.A., they are compatible with earth resistance me-
ters of MRU series and multifunctional meters of MPI series.
The output signal is conducted by a cable (1.5 m) ended with a pin adapted to the socket on the
meter.
