PANEL INTRODUCTION
11
12 12
13
14
15
16
1/4” TS mono input jack for plugging in your instrument
2 × 1/4” TS stereo output jacks for plugging in amps or other equipment
1/8” TRS stereo input for connecting external devices (phone, MP3 player)
1/8” TRS stereo output for plugging in headphones
USB Type-C connects to computer for use with supporting edit
software or connects to computer/phone as an audio interface
Plug in the DC 9V center negative power jack
