Rear view
Fig. 5: Rear view
Item
(Fig. 5)
Designation Function
1 DAB/FM
ANTENNA
Port for one of the antennae (included) or an external antenna.
2 Battery com-
partment
The battery (CR2032 button cell, 3V) ensures continued operation of the clock in
case of power failure.
3 Bass reflex
opening
Bass response is enhanced.
4 Keylock Anti-theft protection port.
5 AC adapter
port
15.5 V connection for the AC adapter (included).
6 USB charger &
playback
Port for a USB stick or a USB cable.
Port for charging external devices via a USB cable (DC 5 V, 1 A).
7 Headphones Port for headphones.
8 AUX IN Port for external audio devices.
53
