Sony 500WSPL - Specifications

Appendix 131
Appendix
Video S/N ratio (output from the VIDEO OUT
connector) 63 dB (typical) (DSR-500WSL)
61 dB (typical) (DSR-500WSPL)
Registration 0.05% for all zones, without lens
Input connectors AUDIO IN CH-1/CH-2:XLR-3 pin
× 2, female
–60 dBu, 3 kΩ
+4 dBu, 10 kΩ
(0 dBu = 0.775 Vrms)
GEN LOCK IN: BNC
1.0 Vp-p, 75 Ω
VIDEO IN: BNC
1.0 Vp-p, 75 Ω
(When fitting DSBK-501/501P.
The connector shares with GEN
LOCK IN)
TC IN: BNC
0.5 to 18 Vp-p, 10 kΩ
DC IN: XLR-4 pin, male
Output connectors
DV OUT: 6-pin IEEE1394, × 1
AUDIO OUT CH-1/CH-2: phono
jack
–10 dBu, 47 kΩ
(0 dBu = 0.775 Vrms)
VIDEO OUT:
BNC, 1.0 Vp-p, 75 Ω
MONITOR OUT:
BNC, 1.0 Vp-p, 75 Ω
S VIDEO OUT: DIN 4 pin
1.0 Vp-p, 75 Ω
TC OUT: BNC, 1.0 Vp-p,
75 Ω
DC OUT: 4 pin, female
EARPHONE: mini-jack
–∞ to –15.5 dBu variable, 8 Ω
LENS: 12-pin
VF: 20-pin
VTR: 26-pin
LIGHT : 2-pin
Control connectors
REMOTE 1: stereo mini-jack
REMOTE 2: 10-pin
Power supply 11 to 17 V DC
Power consumption
24 W
Operating temperature
0°C to 40°C (32°F to 104°F)
Specifications
DSR-500WSL/500WSPL
Imaging element Three-chip interline transfer CCD
Pixel resolution 980 (horizontal) × 494 (vertical)
(DSR-500WSL)
980 (horizontal) × 582 (vertical)
(DSR-500WSPL)
Imaging area 9.6 × 5.4 mm (corresponds to
2
/3-
inch picture tube)
Built-in filter settings
1: 3200K
2: 5600K +
1
/8ND
3: 5600K
4: 5600K +
1
/64ND
Lens mount Sony
2
/3-inch bayonet mount
Signal standards EIA standard signal (NTSC color
system) (DSR-500WSL)
CCIR standard signal (PAL colour
system) (DSR-500WSPL)
Scanning system 525 lines, 2:1 interlace (DSR-
500WSL)
625 lines, 2:1 interlace
(DSR-500WSPL)
Scanning frequencies
Horizontal: 15.734 kHz
(DSR-500WSL)
15.625 kHz (DSR-500WSPL)
Vertical: 59.94 Hz (DSR-500WSL)
50.00 Hz (DSR-500WSPL)
Synchronization Internal sync
External sync, using signal input
(VBS or BS) to the GEN LOCK
IN/VIDEO IN connector or
input to the VTR connector.
Horizontal resolution
1)
16:9 Mode: 800 TV lines (center)
4:3 Mode: 850 TV lines (center)
Minimum illumination
0.5 lux (at F/1.4, +36 dB)
0.8 lux (at F/1.8, +36 dB)
Sensitivity 2000 lux (F/11.0 standard, 3200 K)
Gain levels Selectable –3 dB, 0 dB, 3 dB, 6 dB,
9 dB, 12 dB, 18 dB, 18 dB +
DPR, 24 dB, 24 dB + DPR, hyper
gain
1) For details on measuring horizontal resolution, see page
134.
..........................................................................................................................................................................................................
