132 Appendix
Appendix
Storage temperature
–20°C to +60°C (–4°F to 140°F)
Mass 3.6 kg approx. (7 lb 15 oz)
(camcorder only)
External dimensions in millimeters (inches)
Tape transport system
Tape speed Approx. 28.2 mm/s
Recording/playback time (using PDV-184ME)
Max. 184 minutes
Fast forward/rewind time (using PDV-184ME)
Max. 12 minutes
Usable cassettes
Video system (at playback with the DSR-85/
85P)
Specifications
Audio system (at playback with the DSR-85/
85P)
DXF-801/801CE Viewfinder
Picture tube 1.5-inch monochrome
Indicators REC/TALLY (×2), BATT, TAKE,
SHUTTER, GAIN UP
Resolution 600 TV lines
Power supply 12 V DC
Power consumption
2.1 W
Mass 620 g approx. (1 lb 5 oz)
Maximum external dimensions
241 (W) × 91 (H) × 203 (D) mm
(9
1
/2 × 3
5
/8 × 8 inches)
RM-LG1 Remote Control Unit
Dimensions 85 × 25 × 12 mm (3
3
/8 × 1 ×
1
/2
inches) (excluding projections)
Mass Approx. 50 g (1 oz) (including
cable)
Cable 5 m (16 feet), with mini-plug
Operating temperature range
–10°C to +45°C (14°F to 113°F)
Storable temperature range
–20°C to +60°C (–4°F to 140°F)
Accessories Stickers (1 set)
Panning rod mounting bracket (1)
242 (9
5
⁄ 8 )
536 (21
1
⁄ 8 )
280 (11
1
⁄ 8 )
192 (7
5
⁄
8
)
247 (9
3
⁄
4
)
121
(4
7
⁄ 8 )
K-factor (K2T, KPB)
Bandwidth DSR-500WSL: 30 Hz to
5.0 MHz ±1.0 dB
DSR-500WSPL: 25 Hz to
5.5 MHz +1.0/–2.0 dB
Luminance (Y)
Chrominance
(R–Y/B–Y)
DSR-500WSL: 30 Hz to
1.5 MHz +1.0/–5.0 dB
DSR-500WSPL: 25 Hz to
2.0 MHz +1.0/–2.0 dB
S/N ratio Luminance Min. 55 dB
Max. 2%
Y/C time delay Max. 30 nsec.
Model name Size
PDV-64ME/64MEM/94ME/124ME/
124MEM/184ME/184MEM
Standard size
PDVM-12ME/22ME/32ME/32MEM/
40ME/40MEM
Mini size
Frequency response 2-channel mode: 20 Hz to 20 kHz
+0.5/–1.0 dB
4-channel mode: 20 Hz to 14.5
kHz +0.5/–1.0 dB
Dynamic range Min. 80 dB
Distortion (THD) (1 kHz,
reference level, 48 kHz)
Max. 0.08%
