Chapter 1 Overview

Chapter 1 Overview 7

Product Configurations

Chapter 1 Overview

VCT-U14 Tripod

Adaptor

Microphone (with the

wind screen attached)

DXF-801/801CE Viewfinder

Test chart for flange

focal length

adjustment

DSR-500WS/500WSP

Camcorder

Shoulder strap

RM-LG1 Remote

Control Unit

Switch guard*

* The switch guard can be removed. (See page 12.)

The DSR-500WSL/500WSPL consists of the following items:

• Lens mount cap

• Binding tie

• Operating instructions
