Chapter 2 Fitting and Connections

Chapter 2 Fitting and Connections 33

Remove lens hood

Lens hood fixing

knob

Filter (optional)

Fitting optional filters

Loosen the lens hood fixing knob to remove the lens

hood, then attach the filter.
