74 Chapter 3 Shooting

Chapter 3 Shooting

When recording in ClipLink mode is started and

previous recording is overwritten

When recording in ClipLink mode is started after a

previous recording

recording

New

recording

Previous Index Pictures:

erased

New Index Pictures are

recorded (when the

DSBK-301A is fitted).

ClipLink log data: overwritten by new data

Previous Index Pictures:

retained but invalid

New Index Pictures are

recorded (when the

DSBK-301A is fitted).

New

recording

ClipLink log data: overwritten by new data
