Appendix
Specifications
60
Specifications
System
Video signal BRC-300: NTSC color, JEITA
standards
BRC-300P: PAL color, CCIR
standards
Synchronization
Internal/external synchronization
automatically switched
Picture element 1/4.7 type, 3CCD (Advanced HAD)
Total picture elements: Approx.
1,070,000 pixels
Effective picture elements: Approx.
1,020,000 pixels
Lens 12
× (optical), 4× (digital)
f = 3.6 to 43.2 mm, F1.6 to F2.8
Horizontal angle
3.3 to 37.8 degrees (4:3)
4.0 to 45.4 degrees (16:9)
Minimum object distance
300 mm (11
7
/
8
inches) (WIDE end)
Minimum illumination
7 lux (F1.6) with 25 IRE
Shutter speed 1/4 to 1/10,000 sec. (BRC-300)
1/3 to 1/10,000 sec. (BRC-300P)
Horizontal resolution
600 TV (WIDE end, 4:3 mode)
Video S/N 50 dB
Pan/tilt action Horizontal: ±170 degrees
Maximum panning speed: 60
degrees/sec.
Minimum panning speed: 0.25
degrees/sec.
Vertical: +90 degrees, -30 degrees
Maximum tilting speed: 60 degrees/
sec.
Minimum tilting speed: 0.25
degrees/sec.
Input/output connectors
Video output BNC type (1), 1 Vp-p, 75 ohms
unbalanced, sync negative
S-video output Mini DIN 4-pin type (1)
Y: 1 Vp-p, sync negative
C: same level as the chroma level of
video output, 75 ohms
Control input/output
VISCA RS-232C IN: Mini DIN 8-pin
type
VISCA RS-232C OUT: Mini DIN 8-
pin type
VISCA RS-422: 9-pin type
Control signal format
9600 bps/38400 bps
Data: 8 bit
Stop bit: 1
Power connector
JEITA type4 (DC IN 12V)
General
Input voltage 12 V DC (10.8 to 13.2 V DC)
Current consumption
1.8 A max. (at 12 V DC), 21.6 W
without optional interface cards
Operating temperature
0ºC to +40ºC (32ºF to 104ºF)
Storage temperature
-20ºC to +60ºC (-4ºF to 140ºF)
Dimensions Video camera: 180 × 210.1 × 205 mm
(7
1
/
8
× 8
3
/
8
× 8
1
/
8
inches) (w/h/d)
(excluding protruding parts)
Remote Commander: 56 × 26 × 210
mm (2
1
/
4
× 1
1
/
16
× 8
3
/
8
inches) (w/
h/d)
Mass Video camera: Approx. 2.5 kg (5 lb 8
oz)
Remote Commander: 110 g (3.9 oz)
Installation angle
Less than ±15 degrees to the horizontal
surface
Supplied accessories
AC power adaptor (1)
AC power cord (1)
Remote Commander (1)
Ceiling bracket (A) (1)
Ceiling bracket (B) (1)
Wire rope (1)
Screws (+ M3 × 8) (7)
RS-422 connector plug (1)
Operating Instructions (1)
Design and specifications are subject to change without
notice.
