Chapter 2 Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 26(E).
•The arrow mark (÷) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not have
any sub-list.
[C] (1/2) INPUT CONFIG (1/2) menu
Set input signal data for each channel.
CH x: Current channel is indicated. To change the
channel, enter a channel number with the numeric
keypad. The settings below will be stored as
information of this channel.
FORMAT... : Select the input signal type. ÷[C1]
SLOT NO: Select the slot number.
INPUT NO: Select the input connector number.
EXT SYNC SLOT: Select the slot when the external
sync signal is used.
AUDIO INPUT (BVM-D9H5U/D9H5E/D9H5A
only): Select the audio input number.
COLOR TEMP: Select the color temperature.
APERTURE VALUE: Enter the aperture adjustment
value (0 to 200).
CHANNEL NAME: Give the channel a name.
÷[C2]
[C] (2/2) INPUT CONFIG (2/2) menu
Set input signal data for each channel.
CH x: Current channel is indicated. To change the
channel, enter a channel number with the numeric
keypad. The settings below will be stored as
information of this channel.
1125/60I SYSTEM: Select the number of active
scanning lines per frame for 1125/60I input
signals. When the HD SDI signal is input, the
number of active scanning lines is selected
automatically.
1035: The active scanning lines are 1035 lines.
1080: The active scanning lines are 1080 lines
Setting Lists in the INPUT CONFIG Menu
H PHASE: Set the horizontal picture position (–32 to
+31).
MARKER PHASE: Set the 4:3 marker position.
MARKER WIDTH: Set the 4:3 marker width.
NTSC SET UP: Set the setup level when the BKM-
127W is installed. SETUP 7.5 or 0.
YPBPR MATRIX: Select the matrix when YP
BPR
signals of the signal format 480/60I or 480/60P
(TV lines 525) are input.
VCR MODE: Compensate for a distorted picture
when the input signals from the VCR are not
typical. This mode is effective when the signal
formats 480/60I or 575/50I are input.
ON: Operates when the signal formats 480/60I or
575/50I are input.
OFF:Does not operate.
[C1] FORMAT menu
Select the signal format.
YPBPR: Select the component signals when the
BKM-129X is installed. SPMTE, BETACAM 7.5
or 0.
RGB: Select when the BKM-129X is installed.
NTSC, PAL: Selects when the BKM-127W is
installed.
D1-SDI: Select when the BKM-120D is installed.
HD-SDI: Select when the BKM-142D is installed.
[C2] CHANNEL NAME menu
Give the channel a name. Enter a name after a preset
one or a new one.
PROG: Program signal.
EDIT: Signal from an editor.
CAM: Camera signal.
VTR: Signal from a VTR.
NEW NAME: Enter a new name. (Up to 20 characters
can be entered and up to six characters from the
head of the name are displayed in the INPUT
CONFIG menu ([C] 1/2).)
C Setting the Input Configuration — INPUT CONFIG Menu
