Sony BVM-D14H5E - BVM-D9 H1 U;D9 H1 E;D9 H1 A;D9 H5 U;D9 H5 E;D9 H5 A Rear Panel

12 (E)
Chapter 1 Overview
BVM-D9H1U/D9H1E/D9H1A/D9H5U/D9H5E/D9H5A Rear Panel
For the BVM-D14H1U/D14H1E/D14H1A/D14H5U/D14H5E/D14H5A, see pages 21(E) to 23(E).
BVM-D9H5U/D9H5E/D9H5A
BVM-D9H1U/D9H1E/D9H1A
Location and Function of Parts
1 PARALLEL REMOTE
1/2 connectors
2 DC 12V IN jack
3 EJECT button
4 AC adaptor/battery
attachment place
5 SERIAL REMOTE
connectors
6 Input option slots
7 Analog input/output
connectors
8 AUDIO IN/OUT
(input/output) jacks
1 PARALLEL REMOTE
1/2 connectors
2 DC 12V IN jack
3 EJECT button
4 AC adaptor/battery
attachment place
5 SERIAL REMOTE
connectors and SERIAL
REMOTE/CTRL UNIT
select switch
6 Input option slots
7 Analog input/output
connectors
