32 (E)
Chapter 2 Menu
[A] CONTROL PRESET ADJ menu
Select the setting method.
MANUAL... : Set with the MANUAL adjustment
knobs. ÷[A1]
AUTO... : Set by automatic adjustment. ÷[A2]
[A1] MANUAL menu
Adjust values by turning the CHROMA, PHASE,
CONTRAST, and/or BRIGHT knobs. After the
adjustment, press the ENTER or Ent button to confirm
the adjusted values.
The setting value is 0 to 200.
CHROMA: xxx
PHASE: xxx
CONTRAST: xxx
BRIGHT: xxx
When you want to erase characters from the screen
while adjusting manually
Press the [F1] button. The characters disappear. To
display characters, press the [F1] button again.
To reset the setting to the default
Press the corresponding MANUAL adjustment button
(BVM-D14H5U/D14H5E/D14H5A) or knob (BVM-
D9H5U/D9H5E/D9H5A.) The adjusted value is reset
to 100 (default).
[A2] AUTO menu
You can adjust the CHROMA and PHASE levels
automatically. Input the color bar signals to the board
to be adjusted and select the required color bar signals.
÷Adjustment is carried out.
8COLOR BAR 100%: 100% full-field 8-color bar
(white, yellow, cyan, green. magenta, red, blue,
black)
8COLOR BAR 75%: 75% full-field color bar (with
100% white signal)
SMPTE COLOR BAR: SMPTE standard color bar
EIA COLOR BAR: EIA standard color bar
Note
When you execute the AUTO menu, SYNC button
should be set to OFF (INT SYNC).
EXT SYNC will cause an error abortion of auto
adjustment procedure.
A Preset Adjustment of the Picture Level Control Knobs — CONTROL PRESET ADJ Menu
