Sony BVM-D14H5E - BVM-D14 H1 U;D14 H1 E;D14 H1 A;D14 H5 U;D14 H5 E;D14 H5 A Rear Panel

21 (E)
Chapter 1 Overview
BVM-D14H1U/D14H1E/D14H1A/D14H5U/D14H5E/D14H5A Rear Panel
BVM-D14H5U/D14H5E/D14H5A
BVM-D14H1U/D14H1E/D14H1A
1 PARALLEL REMOTE
1/2 connectors
2 SERIAL REMOTE
connectors
3 Input option slots
4 Analog input/output
connectors
5 MAIN POWER switch
6 AC IN connector
1 PARALLEL REMOTE
1/2 connectors
2 SERIAL REMOTE
connectors
3 Input option slots
4 Analog input/output
connectors
5 MAIN POWER switch
6 AC IN connector
7 CONTROL UNIT
connector
(continued)
