Sony BVM-D14H5E - BVM-D14 H1 U;D14 H1 E;D14 H1 A;D14 H5 U;D14 H5 E;D14 H5 A Front Panel

16 (E)
Chapter 1 Overview
Location and Function of Parts
BVM-D14H1U/D14H1E/D14H1A/D14H5U/D14H5E/D14H5A Front Panel
BVM-D14H5U/D14H5E/D14H5A
BVM-D14H1U/D14H1E/D14H1A
1 Tally lamp
2 POWER switch
3 DEGAUSS button
4 Numeric keypad
5 MANUAL adjustment
buttons and knobs
6 Menu operation buttons
7 POWER lamp
8 STANDBY lamp
9 OVER LOAD lamp
0 SHIFT button
qa Function buttons
qs OPTION connector
1 Tally lamp
7 POWER lamp
8 STANDBY lamp
9 OVER LOAD lamp
qs OPTION connector
