47 (E)
Chapter 3 Appendix
Nominal chromaticity coordinates:
EBU phosphor
Dimensions (w/h/d)
BVM-D9H1U/D9H1E/D9H1A:
approx. 217 × 174 × 364.5mm
(8
5
/
8
× 6
7
/
8
× 14
3
/
8
inches)
when the AC adaptor is installed:
approx. 217 × 174 × 438mm
(8
5
/
8
× 6
7
/
8
× 17
1
/
4
inches)
BVM-D9H5U/D9H5E/D9H5A:
approx. 217 × 218 × 379.5mm
(8
5
/
8
× 8
5
/
8
× 15 inches)
when the AC adaptor is installed:
approx. 217 × 218 × 453mm
(8
5
/
8
× 8
5
/
8
× 17
7
/
8
inches)
BVM-D14H1U/D14H1E/D14H1A:
approx. 346 × 280 × 519mm
(13
5
/
8
× 11
1
/
8
× 20
1
/
2
inches)
BVM-D14H5U/D14H5E/D14H5A:
approx. 482 × 280 × 562mm
(19 × 11
1
/
8
× 22
1
/
4
inches)
Including all protruding parts
Specifications
General
System 15.625 kHz – 45 kHz
(For details, see “Available Signal
Format” on page 53(E).)
CRT
BVM-D9H1U/D9H1E/D9H1A/D9H5U/D9H5E/
D9H5A
HR Trinitron, 4:3 aspect ratio
Aperture grille pitch: 0.25 mm
90 degree deflection, 21.6 mm
diameter in-line gun
Effective picture size with 16:9
aspect ratio:
155.4 × 87.4 mm (6
1
/
8
× 3
1
/
2
inches) (w/h)
178 mm (7
inches) (diagonal size)
Effective picture size with 4:3
aspect ratio:
155.4 × 115 mm (6
1
/
8
× 4
5
/
8
inches) (w/h)
190.7 mm (7
1
/
2
inches) (diagonal
size)
CRT protection: EHT (extremely
high tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 15 kV with no
beam current
BVM-D14H1U/D14H1E/D14H1A/D14H5U/
D14H5E/D14H5A
HR Trinitron, 4:3 aspect ratio
Aperture grille pitch: 0.25 mm
90 degree deflection, 29.4 mm
diameter in-line gun
Effective picture size with 16:9
aspect ratio:
267.5 × 150.5 mm (10
5
/
8
× 6
inches) (w/h)
306.9 mm (12
1
/
8
inches)
(diagonal size)
Effective picture size with 4:3
aspect ratio:
267.5 × 200.6 mm (10
5
/
8
× 8
inches) (w/h)
331.6 mm (13
1
/
8
inches)
(diagonal size)
CRT protection: EHT (extremely
high tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 23 kV with no
beam current
xy
R 0.640 0.330
G 0.290 0.600
B 0.150 0.060
Chapter 3 Appendix
