Sony CCD-CCD-TRV49E - Hinge Assembly (Trv Model)

2-14
2-13.HINGE ASSEMBLY (TRV MODEL)
2-12.MECHANISM DECK
2 Two claws
1 Screw
(M2 × 3),
lock ace, p2
1 Three screw
s
(M2 × 3),
lock ace, p2
2 MD frame A
3
4
Control switch block
(FK-1000)
3 Mechanism deck
1 Claw
B
B
C
A
2
Slide it in the direction
of the arrow A and
disengage the claws B
Remove the LS lid
assembly in the direction
of the arrow C .
A
A
7 Control switch block
(PR-10000)
1 FP-260 flexible
board (16P)
2 Push switch (2P)
4 Hinge blind,
Push switch
3 Three tapping
screws (B2 × 5)
6 Screw
(M1.7 × 2.5)
5 Four tapping
screws (B2 × 5)
6
1 Four claws
2 Hinge cover C
3 Hinge cover M
4 Harness clamp
8 Hinge assembly
5 Harness (PD-110)
(Remove the LCD unit reffering to section 2-2 before starting disassembling.)
