Sony CCD-CCD-TRV49E - Focus;Zoom Motor Drive, Rec;Pb Amp, Line; Printed Wiring Board

CCD-TR618/TR618E/TR718E/TR728E/TR818/TRV49/TRV49E/TRV58/
TRV58E/TRV59E/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E
4-40
CAMERA, VIDEO, AUDIO, SERVO, MODE/HI CONTROL, D-D CON
VC-251
VC-251 (CAMERA PROCESSOR, Y/C PROCESSOR, FOCUS/ZOOM MOTOR DRIVE, REC/PB AMP, LINE I/O AMP, SERVO,
MODE CONTROL, HI CONTROL, AUDIO, DC/DC CONVERTER, CONNECTOR) PRINTED WIRING BOARD
— Ref. No. VC-251 Board; 10,000 Series —
C
BE
3
21
3
21
For printed wiring board
• Refer to pages 4-72,4-73 for parts location.
• VC-251 board consists of multiple layers.
However, only the sides (layers) A and B are
shown.
• Chip parts
Transistor Diode
There are a few cases that the part
printed on this diagram isn’t mounted
in this model.
VC-251
CAMERA PROCESSOR, Y/C PROCESSOR,
FOCUS/ZOOM MOTOR DRIVE, REC PB AMP,
LINE I/O AMP, SERVO, MODE CONTROL,
HI CONTROL, AUDIO, DC/DC CONVERTER
VF-129 (B/W EVF model
)
(B/W EVF)
