B/W EVF
VF-129
VF-129 (B/W EVF) PRINTED WIRING BOARD
— Ref. No. VF-129 Board; 1,000 Series —
For printed wiring board
• Refer to page 4-71 for parts location.
• VF-129 board consists of multiple layers. However, only
the sides (layers) A and B are shown.
• Chip parts
Transistor
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
C
BE
VC-251
CAMERA PROCESSOR, Y/C PROCESSOR,
FOCUS/ZOOM MOTOR DRIVE, REC PB AMP,
LINE I/O AMP, SERVO, MODE CONTROL,
HI CONTROL, AUDIO, DC/DC CONVERTER
VF-129 (B/W EVF model
(B/W EVF)
