Sony CDP-CE245 - Printed Wiring Board - BD Board

1818
CDP-CE245/CE345
6-2. PRINTED WIRING BOARD – BD Board –• See page 17 for Circuit Boards Location.
A
05
05
TP
(GND)
TP
(FE1)
TP
(RF)
TP
(VC)
TP
(FE)
TP
(TE)
TP
(AGCCON)
TP
(PLCK)
(LIMIT)
(SPINDLE)
(SLED)
(CONDUCTOR SIDE)
(COMPONENT SIDE)
(Page 22)
• Semiconductor
Location
Ref. No. Location
Q101 C-3
• Semiconductor
Location
Ref. No. Location
IC101 C-2
IC102 B-1
IC103 B-1
