Sony CDP-CE245 - Key, Loading Motor, Main Board Parts

41
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
KEY LOADING MOTOR MAIN
1-676-539-11 KEY BOARD
**********
< CONNECTOR >
CN812 1-750-185-11 CONNECTOR, BOARD TO BOARD 4P
< RESISTOR >
R824 1-249-415-11 CARBON 680 5% 1/4W
R825 1-249-417-11 CARBON 1K 5% 1/4W
R826 1-249-419-11 CARBON 1.5K 5% 1/4W
R827 1-249-421-11 CARBON 2.2K 5% 1/4W
R828 1-247-843-11 CARBON 3.3K 5% 1/4W
R829 1-249-427-11 CARBON 6.8K 5% 1/4W
R830 1-249-415-11 CARBON 680 5% 1/4W
R831 1-249-417-11 CARBON 1K 5% 1/4W
R832 1-249-419-11 CARBON 1.5K 5% 1/4W
R833 1-249-421-11 CARBON 2.2K 5% 1/4W
< SWITCH >
S813 1-771-349-21 SWITCH, KEYBOARD (DISC5)
S814 1-771-349-21 SWITCH, KEYBOARD (DISC4)
S815 1-771-349-21 SWITCH, KEYBOARD (DISC3)
S816 1-771-349-21 SWITCH, KEYBOARD (DISC2)
S817 1-771-349-21 SWITCH, KEYBOARD (DISC1)
S818 1-771-349-21 SWITCH, KEYBOARD (PEAK SEARCH)
S819 1-771-349-21 SWITCH, KEYBOARD (EDIT/TIME FADE)
S820 1-771-349-21 SWITCH, KEYBOARD (TIME)
S821 1-771-349-21 SWITCH, KEYBOARD (REPEAT)
S822 1-771-349-21 SWITCH, KEYBOARD (PROGRAM)
S823 1-771-349-21 SWITCH, KEYBOARD (SHUFFLE)
S824 1-771-349-21 SWITCH, KEYBOARD (CONTINUE)
**************************************************************
1-676-244-11 LOADING MOTOR BOARD
*********************
**************************************************************
A-4725-005-A MAIN BOARD, COMPLETE (US, CND)
A-4725-009-A MAIN BOARD, COMPLETE (AEP, UK, SP, AUS)
A-4725-010-A MAIN BOARD, COMPLETE (E, EA)
**********************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C301 1-161-494-00 CERAMIC 0.022uF 25V
C302 1-104-664-11 ELECT 47uF 20% 16V
C303 1-161-494-00 CERAMIC 0.022uF 25V
C304 1-164-159-11 CERAMIC 0.1uF 50V
C325 1-161-494-00 CERAMIC 0.022uF 25V
C326 1-104-664-11 ELECT 47uF 20% 16V
C351 1-126-963-11 ELECT 4.7uF 20% 50V
C401 1-126-965-11 ELECT 22uF 20% 50V
C404 1-104-665-11 ELECT 100uF 20% 10V
C407 1-162-290-31 CERAMIC 470PF 10% 50V
C501 1-126-965-11 ELECT 22uF 20% 50V
C504 1-104-665-11 ELECT 100uF 20% 10V
C507 1-162-290-31 CERAMIC 470PF 10% 50V
C602 1-126-936-11 ELECT 3300uF 20% 16V
C603 1-126-942-61 ELECT 1000uF 20% 16V
C604 1-126-963-11 ELECT 4.7uF 20% 50V
C605 1-126-963-11 ELECT 4.7uF 20% 50V
C606 1-126-963-11 ELECT 4.7uF 20% 50V
C607 1-126-941-11 ELECT 470uF 20% 6.3V
C608 1-104-666-11 ELECT 220uF 20% 10V
C609 1-128-552-11 ELECT 47uF 20% 63V
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-126-767-11 ELECT 1000uF 20% 16V
C612 1-161-494-00 CERAMIC 0.022uF 25V
C613 1-126-941-11 ELECT 470uF 20% 6.3V
C616 1-161-494-00 CERAMIC 0.022uF 25V
C619 1-104-664-11 ELECT 47uF 20% 16V
0 C620 1-113-924-11 CERAMIC 0.0047uF 20% 250V
C622 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN301 1-784-798-11 CONNECTOR, FFC 37P
CN302 1-784-782-11 CONNECTOR, FFC 21P
CN311 1-573-911-11 PIN, CONNECTOR 13P
CN603 1-792-131-11 LEAD (WITH CONNECTOR)
< DIODE >
D350 8-719-991-33 DIODE 1SS133T-77
D351 8-719-991-33 DIODE 1SS133T-77
D353 8-719-991-33 DIODE 1SS133T-77
D601 8-719-200-82 DIODE 11ES2-TA1B
D602 8-719-200-82 DIODE 11ES2-TA1B
D603 8-719-200-82 DIODE 11ES2-TA1B
D604 8-719-200-82 DIODE 11ES2-TA1B
D605 8-719-200-82 DIODE 11ES2-TA1B
D606 8-719-923-60 DIODE MTZJ-T-77-9.1
D607 8-719-991-33 DIODE 1SS133T-77
D608 8-719-921-40 DIODE MTZJ-T-77-4.7B
D609 8-719-991-33 DIODE 1SS133T-77
< GROUND TERMINAL >
EB601 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC301 8-752-912-66 IC CXP82324-091Q
IC303 8-749-921-12 IC GP1F32T (DIGITAL OUT OPTICAL)
IC350 8-759-145-58 IC BA4558
IC601 8-759-061-65 IC LA5602
IC602 8-749-011-78 IC BA17807T
IC603 8-759-633-42 IC M5293L
< JACK >
J301 1-785-868-11 JACK, PIN 2P (ANALOG OUT)
< COIL >
L601 1-412-473-41 INDUCTOR 0uH
L602 1-414-151-21 INDUCTOR 470uH
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC2785-HFE
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
