Sony CDP-CE245 - Display and Junction Board Parts

40
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R124 1-216-097-00 RES-CHIP 100K 5% 1/10W
R131 1-216-037-00 METAL CHIP 330 5% 1/10W
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R147 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-680-11 METAL CHIP 16K 0.5% 1/10W
R172 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R173 1-216-679-11 METAL CHIP 15K 0.5% 1/10W
R181 1-216-680-11 METAL CHIP 16K 0.5% 1/10W
R182 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R183 1-216-679-11 METAL CHIP 15K 0.5% 1/10W
R184 1-216-025-00 RES-CHIP 100 5% 1/10W
R185 1-216-025-00 RES-CHIP 100 5% 1/10W
< NETWORK RESISTOR >
RN101 1-233-412-11 RES, CHIP NETWORK 1.0K (3216)
RN102 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
A-4725-007-A DISPLAY BOARD, COMPLETE
************************
4-224-880-01 HOLDER (FL)
< CAPACITOR >
C851 1-126-968-11 ELECT 100uF 20% 6.3V
< CONNECTOR >
CN810 1-784-798-11 CONNECTOR, FFC 37P
CN811 1-750-194-11 CONNECTOR, BOARD TO BOARD 4P
< FLUORESCENT INDICATOR TUBE >
FL801 1-517-946-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC802 8-759-648-23 IC RPM6940-H4
< RESISTOR >
R811 1-249-415-11 CARBON 680 5% 1/4W
R812 1-249-417-11 CARBON 1K 5% 1/4W
R813 1-249-419-11 CARBON 1.5K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W
R815 1-247-843-11 CARBON 3.3K 5% 1/4W
R816 1-249-427-11 CARBON 6.8K 5% 1/4W
R817 1-249-415-11 CARBON 680 5% 1/4W
R818 1-249-417-11 CARBON 1K 5% 1/4W
R819 1-249-419-11 CARBON 1.5K 5% 1/4W
R820 1-249-421-11 CARBON 2.2K 5% 1/4W
R821 1-247-843-11 CARBON 3.3K 5% 1/4W
R822 1-249-427-11 CARBON 6.8K 5% 1/4W
R823 1-249-431-11 CARBON 15K 5% 1/4W
R851 1-247-807-31 CARBON 100 5% 1/4W
R852 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S801 1-771-349-21 SWITCH, KEYBOARD (A OPEN/CLOSE)
S802 1-771-349-21 SWITCH, KEYBOARD (x)
S803 1-771-349-21 SWITCH, KEYBOARD (X)
S804 1-771-349-21 SWITCH, KEYBOARD (H)
S805 1-771-349-21 SWITCH, KEYBOARD (FADER)
S806 1-771-349-21 SWITCH, KEYBOARD (MUSIC SCAN)
S807 1-771-349-21 SWITCH, KEYBOARD (DISC SKIP)
S808 1-771-349-21 SWITCH, KEYBOARD (EX-CHANGE)
S809 1-771-349-21 SWITCH, KEYBOARD (CLEAR)
S810 1-771-349-21 SWITCH, KEYBOARD (CHECK)
S811 1-771-349-21 SWITCH, KEYBOARD (M)
S812 1-771-349-21 SWITCH, KEYBOARD (m)
S825 1-475-543-11 ENCODER, ROTARY
(l AMS L PUSH ENTER)
**************************************************************
1-676-246-11 JUNCTION BOARD
***************
< CAPACITOR >
C10 1-124-589-11 ELECT 47uF 20% 16V
C11 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN11 1-573-911-11 PIN, CONNECTOR 13P
CN13 1-506-481-11 PIN, CONNECTOR 2P
* CN14 1-568-941-11 PIN, CONNECTOR 3P
CN15 1-784-767-11 CONNECTOR, FFC 6P
< IC >
IC11 8-759-356-03 IC BA6780
< RESISTOR >
R21 1-249-429-11 CARBON 10K 5% 1/4W
R22 1-249-426-11 CARBON 5.6K 5% 1/4W
R23 1-249-425-11 CARBON 4.7K 5% 1/4W
R24 1-249-430-11 CARBON 12K 5% 1/4W
R25 1-249-382-11 CARBON 1.2 5% 1/6W
R26 1-249-382-11 CARBON 1.2 5% 1/6W
< SWITCH >
S11 1-771-836-11 SWITCH, LEVER (SLIDE)
(OPEN/CLOSE DETECT)
**************************************************************
BD DISPLAY JUNCTION
